A Zero Liquid Discharge (ZLD) process diagram that highlights how wastewater from an industrial process is converted to solids and treated water for reuse via a ZLD plant.
This has led to processes like electrodialysis, forward osmosis, and membrane distillation.
A ZLD system is generally comprised by two steps:
- Pre-Concentration
- Evaporation/Crystallization
